型号
Model | AZTS100-2T | AZTS150-2T | AZTS200-2T | AZTS300-2T | AZTS500-2T | AZTS1000-2T |
电源
Power Supply | 交流380V 50赫兹 3相+N+PE
AC 380V 50HZ 3 phase+N+PE |
最大功率
Maximum Power (KW) | 20 | 25 | 29 | 35 | 45 | 55 |
形式
Type | 两箱式
Two Zone |
提篮驱动方式
Basket moving mechanism | 气动方式，或者电机驱动
Pneumatic Drive or Electrical Motor Drive |
提篮运动方向
Basket moving direction | 垂直方向
Vertical direction | 水平方向
Horizontal direction |
最大提篮负载
Maximum Basket Load | 16kg | 20kg | 30kg | 35kg | 100kg | 150kg |
提篮转换时间
Basket Transfer Time | <10S |
性能*1
Performance*1 | 温度范围
Temperature Range | 低温区:-70℃～-10℃; 高温区:环境温度+20℃～+180℃
Cold Zone: -70℃～-10℃, Hot Zone: Amb+20℃～+180℃ |
温度波动度
Temperature Fluctuation | 高温箱:设定值的±1%或者±1℃,取大者; 低温箱:±1℃
Hot Zone: ±1% of set point or ±1℃, whichever is greater;Cold Zone: ±1℃; |
温度偏差
Temperature Deviation | ≤±2℃ |
恢复时间为2分钟的温度及负载条件
Test condition with load for 2 minutes recovery time | 带2.5kg铁-55℃/+125℃
-55℃/+125℃ with 2.5kg Fe | 带5kg铁-55℃/+125℃
-55℃/+125℃ with 5kg Fe | 带10kg铁-55℃/+125℃
-55℃/+125℃ with 10kg Fe | 带15kg铁-55℃/+125℃
-55℃/+125℃ with 15kg Fe | 带25kg铁-55℃/+125℃
-55℃/+125℃ with 25kg Fe | 带50kg铁-55℃/+125℃
-55℃/+125℃ with 50kg Fe |
恢复时间为5分钟的温度及负载条件
Test condition with load for 5 minutes recovery time | 带0.5kg铁-65℃/+150℃
-65℃/+150℃ with 0.5kg Fe | 带2.5kg铁-65℃/+150℃
-65℃/+150℃ with 2.5kg Fe | 带4kg铁-65℃/+150℃
-65℃/+150℃ with 4kg Fe | 带7kg铁-65℃/+150℃
-65℃/+150℃ with 7kg Fe | 带13kg铁-65℃/+150℃
-65℃/+150℃ with 13kg Fe | 带30kg铁-65℃/+150℃
-65℃/+150℃ with 30kg Fe |
提篮内容积 （升）
Interior Capacity (L) | 102 | 148 | 205 | 294 | 506 | 960 |
内尺寸
Interior Size | W(mm) | 510 | 510 | 620 | 700 | 750 | 1000 |
| D(mm) | 400 | 580 | 660 | 700 | 750 | 800 |
| H(mm) | 500 | 500 | 500 | 600 | 900 | 1200 |
外尺寸
Exterior Size | W(mm) | 1000 | 1000 | 1100 | 1200 | 3600 | 4700 |
| D(mm) | 2100 | 2300 | 2400 | 2650 | 1800 | 2100 |
| H(mm)*2 | 2700（1900） | 2700（1900） | 2700（1900） | 3000（2100） | 1950（1650） | 2250（1950） |
*1: 性能指标在室温为+25℃时测定;传感器处于空气处理单元出风口;
All the above specifications are measured at +25℃ room temperature and the sensors are installed at blow-out of air conditioning unit;
*2：括号中的数字代码拆除气缸（风机电机）之后的高度；
The number in the brackets are the net height excluding the penumatic cyclinder(fan motor);
|
|
|
